AIMB-215D-S6B1E |
AIMB-215L-S6B1E |
AIMB-215N-S6B1E |
AIMB-215U-S6B1E |
| Processor |
CPU |
J1900 |
J1900 |
N2930 |
N2807 |
| Display |
VGA |
Up to 2560 x 1600 |
Up to 2560 x 1600 |
Up to 2560 x 1600 |
Up to 2560 x 1600 |
| Multiple Display |
Dual |
Dual |
Dual |
Dual |
| Ethernet |
Controller |
GbE LAN1: Realtek RTL8111E, GbE LAN2: Realtek RTL8111E |
GbE LAN1: Realtek RTL8111E |
GbE LAN1: Realtek RTL8111E, GbE LAN2: Realtek RTL8111E |
GbE LAN1: Realtek RTL8111E |
| Audio |
CODEC |
Realtek ALC892, High Definition Audio (HD) |
Realtek ALC892, High Definition Audio (HD) |
Realtek ALC892, High Definition Audio (HD) |
Realtek ALC892, High Definition Audio (HD) |
| I/O |
COM Port |
(5 x RS232,1 x RS232/ 422/ 485) |
2 x RS232 |
(5 x RS232,1 x RS232/ 422/ 485) |
2 (RS-232) |
| Display |
LCD (TTL/LVDS/eDP) |
LVDS: dual channel 24-bit up to 1920 x 1200 |
0 |
LVDS: dual channel 24-bit up to 1920 x 1200 |
0 |
| DDI (HDMI/DVI/DisplayPort) |
Display port 1.2 supports up to 2560 x 1600 |
Display port 1.2 supports up to 2560 x 1600 |
Display port 1.2 supports up to 2560 x 1600 |
Display port 1.2 supports up to 2560 x 1600 |
| Expansion |
Slots |
1 x PCIex1, 2 x MiniPCIe |
1 x PCIex1, 1 x MiniPCIe |
1 x PCIex1, 2 x MiniPCIe |
1 x PCIex1, 1 x MiniPCIe
|
